Name: Pitch 2.54 Machined Female Header Connector Right Angle PPS
SKU: YXCON-587
Availability: OutOfStock

Pitch 2.54 Machined Female Header Connector Right Angle PPS

Production Status Discontinued

Capacity Status 0

Inquire Now

Dongguan Yuxi Precision Connector Co., Ltd.

Nikki Cen

No. 2, Yucheng Road, Shaxin Industrial Zone, Chang\\\\\\\'an Town, Dongguan City, Guangdong Province, China

+86 769-8539 7456 / 8539 7457

sales006@yxcon.com

Nikki Cen

+86 13712869134

sales006@yxcon.com

Pitch 2.54 Machined Female Header Connector Right Angle PPS

Pitch 2.54 Machined Female Header Connector.

Specifications

Product Code：YXCON-587 Number of Positions：2P～40P Height：3.0mm

Type:	machined Female Header Connector
Application:	PCB
Interface Type:	DIP
Packaging:	carton box
Supplier Type:	Original manufacturer
Place of Origin:	Guangdong, China
Color:	Black, Black
Description:	Machined Pin Header Connector
Number of Positions:	1-40 PIN/2-40PIN/3-50PIN
Pitch:	1.778mm, 2.54mm,2.mm,1.1mm,5.0mm
Number of Rows:	Single Row, two rows, three rows
Material:	PA6T, PBT, PPS, LCP,PA9T
Plating:	Gold Palting
Housing:	High Temperature Thermoplstics
Contacts:	Copper Contact Gold Plating Contact
Style:	DIP, SMT, straight, right angle
Current Rating	1.0AMP
Contact Resistance	10mΩ Max
Withstand Voltage	200V AC/Minute
Insulation Resistance	500mΩ Min
Operation Tempererature	-55℃ To +105℃
Contact Material	CnZn 36PB3(C3600)
Contact Plating	Au Over Ni
Insulator Material	PPS Black+30%GF UL94-V0
Standard	LCP Or PA6T Or PBT+30%GF
Packing	Tube/reel, PE bag, carton

Specifications

板对板连接器

Tags： Pitch 2.54 Machined Female Header Connector. mahined female connector 2.54 female connector connector
